The DS-2 is the high-performance instrument professionals need to get the job done. A built-in stereo microphone ensures crisp stereo sound and 64MB of internal memory supplies 22 hours of recording time (LP). Record via voice activation or from the easy-to-use buttons on the face of the recorder. With slow, fast, skip, and repeat playback options. Featuring DSS Player software for editing, archiving and more and a USB docking station for fast and easy file transfers. Unit also has audio feedthrough for monitoring recordings as they occur.

DS-2 Special Features

	The built-in stereo microphone records in stereo to pick up both sides of a conversation with equal clarity.
	Enjoy up to 22 hours of recording time for capturing lectures, meetings, interviews, notes and more in LP mode.
	A large, backlit LCD is easy to read so you can be aware of file information, recording time, battery condition, record levels, events and more at all times.
	With 64MB of internal memory, you can record up to 22 hours in LP mode, up to 4 hours in higher quality settings (WMA), and store, organize, and edit your recordings at will.

Compact and ergonomically designed with rounded corners and easy to use buttons
Built-in Stereo Microphone
64MB Internal Memory
Up to 22 hours recording time in LP mode; up to 4 hours in higher quality settings
Large, backlit LCD screen
Files are saved in WMA and DSS file formats
Five (5) quality modes
Included DSS Player Software enables easy archiving, editing and further processing of recordings
Twelve (12) different speed levels (8 in fast playback, 4 in slow playback)
Skip playback and Repeat playback options
Variable Control Voice Actuator (VVCA) setting saves time and battery life by recording only when sound is sensed
Timer recording allows user to set unit to record at desired times
Five (5) folders are capable of storing up to 199 files each
Alarm playback can be set to notify you of important meetings, dates, times, and more \
USB Docking Station for quick and easy downloading/uploading of files between DS-2 and PC/Mac
Long life AAA batteries supply up to 18 hours of continuous operation

DS-2 Specifications

Recording Format WMA(HQ/SSP/SHQ) DSS(LP/SP)
Recording Media Built-in 64MB
Recording Time 22 hours 20 min (LP); 10 hours 25 min (SP); 4 hours 20 min (HQ); 2 hours 10 min (SSP); 1 hour 5 min (SHQ)
Card Format N/A
Input Level N/A
PC Interface USB cable
LCD Large, backlit LCD screen
LED N/A
Folders Messages Five (5) folders capable of storing up to 199 files each
Sampling Frequency SHQ 44.1kHz:128kbps (WMA)
SSP 44.1kHz:64kbps (WMA)
HQ 44.1kHz:32kbps (WMA)
SP 12kHz:13.7kbps (DSS)
LP 8kHz:6.3kbps (DSS)
Overall Frequency Response SHQ 100-17000Hz
SSP 100-8000Hz
HQ 100-7000Hz
SP 200-5000Hz
LP 200-3000Hz
LP Mode Yes
Voice Activation Yes
Output 200 mW
Write Protection No\
Speaker 23 mm
Microphone Jack 3.5 mm/Impedance, 2 kOhm
Earphone Jack 3.5 mm/Impedance, 8 Ohm (Allows Monitoring As Recording Occurs)
Power Supply 2 x 1,5 V/AAA battery
Batteries AAA
External Power Supply No
Battery Life 18 hours
Size 122 x 37.5 x 17.5 (mm)
Weight 80 g (including batteries)
OS Supported N/A
CPU N/A
RAM 64MB
Sound Board N/A
Video Card and Display N/A
Removable Drive N/A
USB Port Yes
Audio Output N/A
