Stay organized and on the move with this high-class storage device and powerful music player. Record meetings or notes and even store large documents to bring from one computer to another. The easy USB input lets you plug the WS-320M right into the computer for fast results. And up to 266 songs can be stored and played in impressive stereo sound with track and artist name clearly displayed on the LCD.

277 HOURS RECORDING TIME. You'll never be hindered from recording audio, notes, lectures and more with an amazing 277 hours of available recording time.	DIRECT PC LINK. Nothing is faster than plugging it right into the USB port on a computer to download or upload files with the cool "USB Direct" design.
LET THE MUSIC PLAY. Store and listen to up to 266 songs for entertainment on the spot whenever you want and wherever you may be.	BUILT-IN STEREO MICROPHONE. From personal notes to school lectures to business-related meetings and music galore, everything sounds great in clear stereo sound from the built-in stereo microphone.

Features and Benefits

Built-in stereo microphone.

"USB Direct" design means you can connect it right to the USB port on your computer and download or transfer audio, music, photos and more.

277 hours of recording time in LP mode or 266 songs (4 minutes with 128kbps per song).

Records in popular Windows Media Audio (WMA) format.

Backlight Full-Dot LCD.

1GB of internal flash memory.

USB mass storage class support means the WS-320M can store documents, images, and more in addition to audio.

Play recordings in Fast and Slow Playback mode (50% faster or 25% slower than real time).

Choose between 4 recording modes: HQ for high quality, LP and SP for extended recording times, and ST HQ for stereo recording.

Organize up to 199 files in each of 5 available folders for quick retrieval and storage convenience.

Use the Voice Activation mode and record sound via the built-in microphone without ever lifting a finger.

Set a portion of an audio file to play back on a repeat basis with the Repeat Playback option.

Remove any chance of files being accidentally erased with the ability to lock them.

Locate important sound bites quickly and easily by inserting index marks where desired.

Erase single or entire files.

Adjust the microphone sensitivity to set the recorder to meet your specific needs.

Up to 15 hours of continuous operation is achieved via 1 x AAA battery for low power consumption.

Supports music files in MP3 and WMA.

WOWTM audio technology provides rich bass and 3-dimensional stereo sound during music playback.

Use the Equalizer Setting to enjoy your favorite types of music with the best possible sound.

Choose between Random and Repeat play back modes.

Piano black finish.

Package Contents

WS-320M Digital Voice Recorder

Stereo Earphone

1 x AAA battery

USB Cable

Instruction Manual

Specifications

Recording Format	WMA (Windows Media Audio)
Recording Media	Built-in 1GB flash memory
Recording Time	Stereo HQ Mode: approx. 35 hours, 25 minutes HQ Mode: approx. 70 hour, 50 minutes. SP Mode: approx. 139 hours, 30 minutes. LP Mode: approx. 277 hours, 20 minutes.
Card Format	N/A
Input Level	-70 dBv
PC Interface	USB direct, 2.0 full speed
LCD	Yes
LED	Yes
Folders Messages	5/199 per folder
Sampling Frequency	Stereo HQ: 44.1kHz/HQ:44.1kHz/SP:22.0kHz/LP:8.0kHz
Overall Frequency Response	Stereo HQ: 100-15,000Hz/HQ:100-12,000Hz/SP:100-5,000Hz/LP:100-3,000Hz
LP Mode	Yes
Voice Activation	Available, Switchable On/Off
Demographic Data Input	N/A
Practical Maximum Output	70 mW
Write Protection	N/A
Speaker	Built-in ø18 mm round dynamic speaker
Microphone Jack	Yes
Earphone Jack	Yes
Power Supply	One AAA battery
Batteries	One AAA battery
External Power Supply	N/A
Battery Life	Approx. 15 hours (using alkaline dry cell battery)
Size	3.73"L x 1.50"W x 0.43"D (excluding protrusions)
Weight	1.62 oz. (46g) including battery
OS Supported	Microsoft Windows ME/2000 Professional/XP Professional, Home Edition
CPU
RAM
Sound Board
Video Card and Display
Removable Drive
USB Port	One free port
Audio Output	Earphone output or speakers

^
